GABRIEL SNUBBERS FITABLE ON ANY CAR It isn't a case now of many of the leading cars having holes in the frames for Gabriel snubbers, says C. J. Nenno of the well known local accessories shop. It's a case of most of the leading cars being so provided. The work of attaching them to the car, therefore, is easy. But it's a simple matter to bore the holes, if necessary. Gabriel snubbers are bolted to the car frame and the belt fastened to the axle either with a bracket or secured around it. Here's how the snubbers work: As the cars springs compress, the spring within the coil expands and takes up the slack in the belting, then as the rebound commences, the coils of belting begin to tighten and create friction on the band of brass between them, thus forming a resistance that increases gradually as the coil compresses the spring within it. This action steadies and controls the car springs, and causes them to regain their normal position gradually without jerk or abrupt stop. The result is the occupants move with the seat instead of being bounced or jolted from it. Gabriel snubbers are adapted to all trucks as well as pleasure cars, they protect same from vibration when light and the contents from damage when loaded. WHAT BATTERY DOES NOT DO IMPORTANT Here are some No's of the Mac-Dry battery which B. F. Hern of 253 North Los Angeles street has been distributing along with other information: No separators. No liquid. No freezing. No corrosion. No sulphation. No buckled plates. No leaking jars. No discharge, even though idle. There’s a size for every car, the PURE RUBBER, MORE OF IT, IN CONVERSE The cushion on the Converse tire is of pure para rubber and binds the tread securely to the carcans, says F. S. Dunlop of the Nu-Way Tire Co. But this is only one of several unusual features in the construction of the tire. Others are: A breaker strip, that distributes road shocks; a lower cushion to absorb road shocks; seven top cord piles, each one rubber impregnated and further insulated by rubber sheets; reinforced side walls, which are trouble proof; non-stretchable bear reinforced with... Here are some No's of the Mac-Dry battery which B. F. Hern of 252 North Los Angeles street has been distributing along with other information: No separators. No liquid. No freezing. No corrosion. No sulphation. No buckled plates. No leaking jars. No discharge, even though idle. There's a size for every car, the cheaper and more popular as well as the most expensive, Ford or Locomobile. The cushion on the Converse tire is of pure para rubber and binds the tread securely to the carcass, says F. S. Dunlop of the Nu-Way Tire Co. But this is only one of several unusual features in the construction of the tire. Others are: A breaker strip, that distributes road shocks; a lower cushion to absorb road shocks; seven top cord piles, each one rubber impregnated and further insulated by rubber sheets; reinforced side walls, which are trouble proof; non-stretchable bear, reinforced with piano wire; Converse special bead lock, constituting a permanent anchor; and extra plies at bead and side walls. DANIELS & WILLIAMS Distributors 211 No. Los Angeles St. Phone 25 Anaheim The Brunswick Red Seal Identifies SedanTires A new tire was needed to meet the severe twist and strain caused by the side away of closed cars. Brunswick is first to meet this new need with the Sedan tire. A special tire for closed cars, naturally a better tire for open cars. Friction-Proofed BRUNSWICK SEDAN TIRES Friction-Proofed BRUNSWICK SEDAN TIRES Friction-Proofed—an exclusive Brunswick treatment—to combat road-burn, and the Sedan feature to resist body strain. Come in. Let us show you why this new Brunswick Sedan tire is the best for your closed car and a tire of super-strength for your open car—the right tire no matter what car you drive. APPOINTED DEALERS LEE'S SERVICE STATION FIVE POINTS SERVICE STATION FLINT'S SERVICE STATION AEROPLANE SERVICE STATION BLUE AND GOLD SERVICE STATION GOLTER'S SERVICE STATION, Placentia SMITH'S SERVICE STATION, Buena Park Manufacturers Established 1843 Here are a few of the principals in the great Auto Resurrection Day festivities to be staged at Santa Ana, Saturday, May 5, by the American Legion. The lengthy gentleman, at the left, is "Jim Crow," said to be the tallest man in California, who will flivver his way to glory in the junk parade. The animated ladies in baseball attire include Miss Corine Crawford and Miss Ruth Graves, two Orange county beauties who will pilot cars in the "Petticoat Special." Above them is seen Eddie Pullen, nationally known racing driver and holder of the world's road race record. He will act as official starter. On the extreme right we have Judge J. B. Cox, nemesis of the speeders, who will act as generalissimo and see that all speeders keep it down to the extreme minimum. Below in the Jackie Coogan Special is Eddie Pullen Jr. He is coming to the race to see his famous dad wave the starter's flag. Entries for the junk classic close Friday, April 27. ALL ESSEX PARTS EVER MADE BUYABLE A parts department which covers every car ever built is one of the features of the Essex factory says G. DODGE GEAR SHIFT UNIQUE, SAYS MANN The gear shift of the Dodge car is unique to it. No other car has it or has had it since the car came out. BUYING DEMAND FOR HUP IS RECORD The existence of a buying demand that will not be wholly equalled by Hummobile production for several ALL ESSEX PARTS EVER MADE BUYABLE A parts department which covers every car ever built is one of the features of the Essex factory, says G. C. Griffith, branch manager of Townsend & Medberry, Hudson and Essex distributors. And not only can any part of any car be obtained, but it can be obtained through any Hudson-Essex distributor or dealer. So much for service. Regarding quality, the mechanical excellence of the Essex is generally accepted by the public, says Griffin. Engineers of America and Europe have called it altogether the finest car of its size. To this tribute nearly 1000,000 owners will add their testimony. The same men who conceived and produced the super-six conceived and produced the Essex. In quality of material and workmanship they are identical. They are built in the same factory. The Hudson organization stands sponsor equally for both. There is no sounder or more permanent organization in the industry. An engineer says we are learning more about internal combustion. At any rate we are eating yeast and elmsing it with grape juices. To overcome self-indulgence, In-State secretaries of C. of C.'s. DODGE GEAR SHIFT UNIQUE, SAYS MANN The gear shift of the Dodge car is unique to it. No other car has it or has had it since the car came out eight years ago, says Charley Mann, local distributor. "It is popular because it is logical. Its design is based on the natural inclinations of the driver. To start, you throw the lever forward. To reverse, you throw the lever backward. And owners also know that it is particularly convenient, when the car is running in high speed, to have the gear shift lever in a forward position, out of the way, where it does not interfere with passengers, robes or luggage. "The use of this unique gear shift requires a special type of transmission—a type developed, patented and used exclusively by Dodge Brothers." This transmission is so designed that the countershaft—used in intermediate speeds and in reverse—is disconnected while the car is running in high gear. Power is transmitted directly to the rear axle. As over 90 per cent of all driving is done in high, thus exclusive feature obviously eliminates a vast amount of wear, in addition to eliminating gear noises and minimizing the loss of power through friction." BUYING DEMAND FOR HUP IS RECORD The existence of a buying demand that will not be wholly equalled by Hupmobile production for several months is reported by O. C. Hutchinson, general sales manager of the Hup Motor Car Corporation, and Fred B. Sides, his assistant, who have just returned to the Detroit plant from a series of trips which have taken them into more than half of the states of the Union since Jan. 1, says M. B. Lacy of the Cadillac Garage Co., local distributors. Beginning with the New York Auto Show, Mr. Sides has attended similar shows in every large city of the country from Boston in the east to Kansas City, and from Minneapolis in the north to Oklahoma City. His trips have taken him to more than 20 of the largest buying centers of the country. At the same time, Mr. Hutchinson has been covering thousands of miles of other territory. Both found the buying interest at the scores of shows held the last three months to be greater than at any previous automobile shows ever given. Information received by Lacy quotes Mr. Sides as stating that hundreds of Hupmobile dealers and distributors, bankers and other businessmen have told him that buying conditions in their respective territories are unusually bright in the cities and improving in the rural sections. More buying power than a year ago is reported from every section of the country, including these sections covered by the two Hup officials as well as those not covered. BENDIX DRIVE IS WONDER INVENTION Increasing his stock of electrical accessories George H. Ennis of the Automotive Electric Co., now has on hand an assortment which in size and variety is hardly equalled anywhere in the city. Ennis this week is pushing the Bendix drive, the wonderful "mechanical arm and hand" which assists in the operation of the electric starter. It automatically takes hold of your flywheel, starts it, and then automatically jets it go. It is the connecting link between the starting motor and the engine. The Bendix drive is used on more than 90 per cent of the autos and trucks manufactured today. CARBURETOR AND IGNITION Generators Starting Motors Repaired by Experts RAYFIELD CARBURETORS RADIO PARTS AND EQUIPMENT ROBERT V. JENSEN Carburetor and Ignition Work 242 East Center St. Anaheim PAIGE Here's an automobile in which beauty is not merely skin deep but goes through and through. Riding comfort, super power and quality are but a few features that made the Paige "America's Most Beautiful Car." Paige closed cars offer a greater realization of motor car refinement. Paige & Jewett AGENCY Phone 302 243 West Center St. Anaheim HOLD THREE AS MURDER SUSPECTS (LOS ANGELES, April 16—The apprehension of a fleeing automobile early today landed three more suspects to the murder Friday of Elmer Estes, a Colton police officer. Officer H. K. Freeman gave chase and after a race of several blocks arrested the trio for reckless driving. CHALMERS COACH, FIRST ONE, HERE The first Chalmers sedan couch to be delivered in Orange County was delivered recently by Turton & Lumadon, Chalmers and Maxwell distributors (to Harry E. Sallade). The car embodies many improvements, and is a mighty nifty looking job. The mechanism is better, the motor more economical, the design more beautiful and dignified and the interior more commodious. At the same time the construction is on practical lines. Henry Huff has purchased a Maxwell sport; George R. Manzo of Placentia a Maxwell touring; George J. Tramer a Maxwell coupe; Dominic Etchandy of Yorba Linda a Chalmers touring and Daniel Moore of Placentia a Maxwell touring. S. F.-OAKLAND CAR MARKET ASS'N. PLAN! San Francisco is interested with Oakland in the establishment of certified markets for used cars similar to the Anaheim and Santa Ana markets for used cars, and an association was expected to be formed this week. The two cities, while in some sense rivals, are tied up by the fact that many of the prominent distributors or cars have Oakland branches. Glendale has organized, Manager C. P. Hamm of the local market announces. San Diego dealers had representatives in Anaheim on Tuesday who visited the market and interviewed Hamm. They appeared much interested in the method of operation. The public seemed to be given cleaner cars at cheaper rates, they told Hamim. President Jim Appleby of the Orange County Motor Car Dealers' Association spoke recently before the San Diego dealers, explaining the plan. CERTIFIED USED CARS SEAL OF SATISFACTION Cut of this "Ad" it is Worth $10.00 On any used car in our Stock We give each and every used car buyer a signed certificate stating the actual condition of the car he buys. Don't conflict certified used cars with the ordinary kind. You can buy one here with just as much confidence as you would buy a new car. Come in and make your selection. 1915 Ford Touring $40.00 1916 Ford Touring $75.00 1917 Ford Touring $90.00 DEMAND UP IS RECORD of a buying demand be wholly equalled by production for several posted by O. C. Hutchisales manager of the Car Corporation, and him assistant, who have to the Detroit plant of trips which have to more than half of the Union since Jan. 1. by the Cadillac Gardistributors. with the New York Mr. Siden has attended in every large city of from Boston in the east, and from Minneapolis to Oklahoma City. His en him to more than 20 buying centers of the time, Mr. Hutchinson ing thousands of miles tory. Both found the at the scores of shows three months to be at any previous autoover given. received by Lacy as stating that hunmobile dealers and distracters and other business him that buying conrespective territories bright in the cities in the rural sections. power than a year ago in every section of the ing those sections covo Hup officials as well covered. DRIVE IS ER INVENTION this stock of electrical George H. Ennis of the electric Co., now has on ment which in size hardly equalled anycity. week is pushing the the wonderful "meand hand" which asperation of the electric automatically takes hold heel, starts it, and then lets it go. It is the sk between the startd the engine. drive is used on more cent of the autos and REAL OF SATISFACTION On any used car in our Stock We give each and every used car buyer a signed certificate statting the actual condition of the car he buys. Don't conflict certified used cars with the ordinary kind. You can buy one here with just as much confidence as you would buy a new car. Come in and make your selection. 1915 Ford Touring ..... $ 60.00 1916 Ford Touring ..... $ 75.00 1917 Ford Touring ..... $ 90.00 1918 Ford Touring ..... $ 100.00 1919 Ford Touring ..... $ 125.00 1920 Ford Touring ..... $ 135.00 1921 Ford Touring ..... $ 145.00 1922 Ford Coupe ..... $ 500.00 1921 Ford Sedan ..... $ 425.00 1922 Ford Sedan ..... $ 450.00 1923 Ford Truck ..... $ 500.00 1920 Mitchell Touring ..... $ 500.00 1920 Chandler ..... $ 600.00 1919 Buick ..... $ 350.00 1918 Paige ..... $ 325.00 All above ready to go. We take your old car on first payment and balance easy terms. Certified Used Car Market Open Evening Till 7:20 P.M. GEORGE DUNTON Ford Lincoln Fordson Sales and Service 222 No. Los Angeles St. Anaheim Phone 263 Under New Management In succeeding Harry Stanley as proprietor of this garage we wish to call particular attention that we have retained the CASE AGENCY. The most practical tractor for this territory. In addition to our sales department we are equipped to render the best of expert service when in trouble, either calling at the ranch or doing the work in our shops. In our shops we are equipped with machinery and expert mechanics, who are familiar with all makes of cars and capable of producing guaranteed work. Mission Garage 243 West Center Street Anaheim Calif. The Good MAXWELL The delightful ease of riding of the good Maxwell has contributed greatly to winning the high favor which it everywhere enjoys. The comfort of the driving position is particularly commented upon by experienced motorists. Turton & Lumsdon Chalmers and Maxwell 152 South Los Angeles St. Service and Parts Phone 32-J Repairs
